# How to run RADAR's bundled abdominal CT research demo

> A documentation-led guide for authorized imaging AI researchers to run RADAR's supplied abdominal CT case, verify a fresh score CSV and understand what the scores cannot show.

By BIGCHANGE.AI Editorial

Published: 2026-10-22T01:47:38.773Z
Updated: 2026-10-22T01:47:38.773Z
Canonical: https://bigchange.ai/blog/radar-abdominal-ct-research-demo-csv-guide

![Conceptual charcoal illustration of a local computer tower beside a monitor showing an unlabeled file grid.](https://bigchange.ai/api/media/file/radar-local-csv-inspection-hero-v2.png)
AI-generated conceptual illustration by BIG CHANGE.

Alibaba DAMO Academy's RADAR repository includes an abdominal CT image, an inference script and an example score CSV. For an imaging AI researcher with a suitable CUDA system and the necessary nonclinical research rights, the useful question is narrower than whether the model can diagnose disease: can you run that supplied case yourself and identify the CSV produced by *your* run? This guide follows the repository and model files at the revisions checked on October 22, 2026. BIG CHANGE inspected the instructions and code but did not install the software, download the model, run inference or verify its results.

## The big change

- **What changed:** RADAR's public repository supplies a concrete, local inference demo for one bundled NIfTI CT case and a CSV of finding scores.
- **Why it matters:** A researcher can check whether a fresh local run produces a labeled score file. That check says nothing by itself about diagnostic accuracy, patient risk or clinical readiness.
- **What to watch:** The path requires suitable CUDA hardware, the right model files and authorized use of the supplied case. The output remains a research score file, not a clinical result.

## Before you start

You need a Linux shell with Git, Conda, Python package installation, sufficient disk space and a working NVIDIA CUDA GPU. The [inference guide](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/docs/INFERENCE.md) names A100 or H20 hardware and says one GPU suffices for its demo. It does not establish a minimum memory figure or that a consumer GPU will fit. The commands below use Bash. Running the script on Windows has not been verified here; its filename handling assumes `/` path separators.

First, establish that your institution and your own permissions allow you to download and use the bundled case for nonclinical research. The public repository and model carry [CC BY-NC-SA 4.0 terms](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/LICENSE), with [separate notices for third-party components](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/THIRD_PARTY_LICENSES.md). Those notices do not independently establish the bundled image's patient provenance, consent or privacy clearance. If your authorization for that case is uncertain, stop before cloning or downloading it. Do not substitute a patient scan or upload one to a service as part of this guide.

The [README](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/README.md) describes RADAR as research-only and says prospective clinical studies are still needed. This demo is not a clinical diagnostic service. Download size, installation time, inference time and cloud-compute charges will depend on your environment; the project does not provide a verified cost or minimum GPU-memory budget for this path. Check your own storage, compute allocation and network policy before starting.

## 1. Get the pinned code and create its environment

The following commands are the repository's documented setup, with an explicit code revision added for reproducibility. Run them only after the rights check above. Use the same Bash session for all command blocks so the run ID and start time remain available. Each failed check below stops that session; resolve the error before opening a new one and continuing.

```shell
git clone https://github.com/alibaba-damo-academy/damo-radar.git || exit 1
cd damo-radar || exit 1
git checkout 0dbf0ece209b77d722588e5e7943014d3db48f7f || exit 1
test "$(git rev-parse HEAD)" = "0dbf0ece209b77d722588e5e7943014d3db48f7f" || exit 1
conda create -n radar python=3.10 || exit 1
conda activate radar || exit 1
pip install -r requirements.txt || exit 1
```

The code-revision check must succeed for `0dbf0ece209b77d722588e5e7943014d3db48f7f`. The repository includes `data/demo_cases/AC423ccbe.nii.gz` and `ckpt/infer_text_embedding_radar.pt`; check that both exist. Installation success has not been tested by BIG CHANGE, and a package conflict should be resolved against the pinned requirements and your CUDA/PyTorch environment before proceeding.

```shell
test -s data/demo_cases/AC423ccbe.nii.gz || exit 1
test -s ckpt/infer_text_embedding_radar.pt || exit 1
python -c "import torch; assert torch.cuda.is_available(), 'CUDA unavailable'; print('CUDA available: True')" || exit 1
sha256sum data/demo_cases/AC423ccbe.nii.gz || exit 1
```

The CUDA check must print `True`; keep the case hash with your run notes to identify the input. A hash records file identity, not permission or clinical validity. The script calls CUDA directly, so a CPU-only setup cannot follow this route.

## 2. Put the model files at the paths the script reads

The demo expects `ckpt/checkpoint_radar_pretrain.pth` and the contents of `ckpt/bert-base-chinese/`. The model repository at revision `3861f2d3e004451c77a6d3afc3e66a9c3e00bc60` lists those files. RADAR's `download_checkpoints.py` helper accepts a destination and include patterns, but has no model-revision argument and otherwise downloads the model repository's current default contents. For an explicitly pinned download, use the [Hugging Face `snapshot_download` API](https://huggingface.co/docs/huggingface_hub/en/package_reference/file_download), which supports `revision`, `allow_patterns` and `local_dir`:

```shell
python - <<'PY'
from huggingface_hub import snapshot_download

snapshot_download(
    repo_id="radar-generalist/RADAR",
    repo_type="model",
    revision="3861f2d3e004451c77a6d3afc3e66a9c3e00bc60",
    local_dir="ckpt",
    allow_patterns=["checkpoint_radar_pretrain.pth", "bert-base-chinese/*"],
)
PY
test "$?" -eq 0 || exit 1
```

This is a reader command, not a download BIG CHANGE performed. It retrieves model files, and the Git and model revision hashes refer to different repositories. Check the file inventory before loading weights. File presence alone cannot prove an interrupted download is complete; if the downloader reports an error, resolve it before inference.

```shell
test -s ckpt/checkpoint_radar_pretrain.pth || exit 1
for file in config.json config_decoder.json pytorch_model.bin tokenizer.json tokenizer_config.json vocab.txt; do
  test -s "ckpt/bert-base-chinese/$file" || exit 1
done
```

These are the six Chinese BERT files listed at that model revision. Keep the bundled `infer_text_embedding_radar.pt` in `ckpt/` as well. Do not use the similarly named `checkpoint_radar_plus.pth` or the separate MERLIN fine-tuned checkpoint for this demo.

## 3. Run the supplied case and distinguish the fresh CSV

The repository already contains `results/RADAR_infer_results_demo.csv` as an example. Its presence is not evidence that your run worked. From the repository root, preserve any file at the default output path, record the start time and the supplied case's hash, then run the [demo script](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/RADAR_inference/inference_demo.py) from `RADAR_inference` with its documented defaults:

```shell
mkdir -p results || exit 1
run_id=$(date -u +%Y%m%dT%H%M%SZ) || exit 1
if test -e results/RADAR_infer_results_demo.csv; then
  test ! -e "results/RADAR_infer_results_demo.pre-run-$run_id.csv" || exit 1
  mv results/RADAR_infer_results_demo.csv "results/RADAR_infer_results_demo.pre-run-$run_id.csv" || exit 1
fi
sha256sum data/demo_cases/AC423ccbe.nii.gz || exit 1
start_epoch=$(date +%s) || exit 1
cd RADAR_inference || exit 1
python inference_demo.py 2>&1 | tee "../results/radar-demo-$run_id.log"
run_statuses=("${PIPESTATUS[@]}")
run_status=${run_statuses[0]}
log_status=${run_statuses[1]}
cd .. || exit 1
printf 'Inference exit status: %s; log exit status: %s\n' "$run_status" "$log_status"
test "$run_status" -eq 0 && test "$log_status" -eq 0 && test -s "results/radar-demo-$run_id.log" || exit 1
```

The defaults read `../data/demo_cases`, write into `../results`, and use the `demo` output tag. The expected output is `results/RADAR_infer_results_demo.csv`. Keep the terminal log and exit status. If the process fails, a CSV left behind by a different attempt, or an incomplete file, cannot establish success.

## 4. Inspect the CSV as model output

Run this check from the repository root after successful inference *and* log capture. It checks the new file's modification time against the recorded start time, hashes it, requires the supplied filename, and compares the full ordered header with the pinned repository example while ignoring that example's scores. The script writes a UTF-8 CSV with a `file_name` column and Chinese finding labels followed by English mappings; its per-finding number is the positive-class value averaged over the available windows.

```shell
START_EPOCH="$start_epoch" python - <<'PY'
import csv
import hashlib
import io
import math
import os
from pathlib import Path
import subprocess

path = Path("results/RADAR_infer_results_demo.csv")
assert path.is_file(), "No new result CSV"
assert path.stat().st_mtime >= int(os.environ["START_EPOCH"]), "CSV predates this run"
with path.open(encoding="utf-8-sig", newline="") as handle:
    reader = csv.DictReader(handle)
    columns = reader.fieldnames or []
    rows = list(reader)
reference = subprocess.run(
    ["git", "show", "0dbf0ece209b77d722588e5e7943014d3db48f7f:results/RADAR_infer_results_demo.csv"],
    check=True, capture_output=True, text=True, encoding="utf-8-sig",
)
expected = next(csv.reader(io.StringIO(reference.stdout)))
assert columns == expected and len(columns) == len(set(columns)), "Incomplete or altered finding header"
assert columns[0] == "file_name" and len(columns) > 1, "Unexpected CSV header"
assert len(rows) == 1 and rows[0]["file_name"] == "AC423ccbe.nii.gz", "Unexpected case row"
for label in columns[1:]:
    value = rows[0][label]
    assert value is not None and value.strip(), f"Blank value: {label}"
    score = float(value)
    assert math.isfinite(score) and 0 <= score <= 1, f"Invalid positive-class value: {label}"
print("Checked fresh CSV:", path)
print("Finding columns:", len(columns) - 1)
print("SHA-256:", hashlib.sha256(path.read_bytes()).hexdigest())
PY
test "$?" -eq 0 || exit 1
```

Keep that hash, the case hash and the process log together. The [checked-in example CSV](https://github.com/alibaba-damo-academy/damo-radar/blob/0dbf0ece209b77d722588e5e7943014d3db48f7f/results/RADAR_infer_results_demo.csv) supplies the expected header only; equal scores are not a required success test. A blank value or missing row is a failure to complete this guide's task, even if the process wrote a CSV. Do not fill blanks or present a partial output as a finding.

## If the run fails

If initialization stops, confirm that the active environment can import the listed dependencies, CUDA is available, and the checkpoint, Chinese BERT directory and bundled text embedding all sit in the paths above. If inference stops or the CSV check fails, retain the log, exit status, input hash and any partial output while investigating the exact error. Check that the supplied case is the only intended file in `data/demo_cases`; the demo script reads that directory. Do not retry with patient data to work around a setup problem.

The output scores are model values for this supplied research example. They are neither diagnoses nor calibrated probabilities of disease for a person. The case comes with no verified clinical ground truth in this guide, so this run cannot measure diagnostic accuracy. The repository's separate MERLIN evaluation path, paper results and any proposed use on arbitrary patient scans require their own evidence, rights and validation. The research-only notice remains in force even when the CSV passes every file check here.
